Product Details
Place of Origin: Jiangsu, China (Mainland)
Brand Name: JIUQI
Certification: RoHS,ISO9001
Model Number: 50KTYZ-JQ-1
Payment & Shipping Terms
Minimum Order Quantity: 100PCS
Price: $5~$8/PCS
Packaging Details: with export carton . Bulk order with pallets
Delivery Time: Trial orders :2 WEEKS Bulk orders: within 3 weeks
Payment Terms: T/T, Western Union,paypal
Supply Ability: 50000 PCS/MONTH
Frequency: |
50Hz/60Hz |
Voltage: |
220V/230V/24V/100V/120V |
Motor Diameter: |
50MM |
Motor Height: |
37.3MM |
Speed: |
Can Be Customized |
Type: |
Synchronous Motor |
Highlight: |
50MM Geared Motor,220V Synchronous Motor |
Product Name: |
Sychronous Motor |
Frequency: |
50Hz/60Hz |
Voltage: |
220V/230V/24V/100V/120V |
Motor Diameter: |
50MM |
Motor Height: |
37.3MM |
Speed: |
Can Be Customized |
Type: |
Synchronous Motor |
Highlight: |
50MM Geared Motor,220V Synchronous Motor |
Product Name: |
Sychronous Motor |
50KTYZ 24V/110V/220V Synchronous Motor High Torque Low Noise For Home Appliance
1. Specification:
| Rated voltage | VAC | 24 | 100 | 110 | 120 | 220 | 230 | ||||||||
| Rated Frequency | Hz | 50,60,50/60 | 50,60,50/60 | 50,60,50/60 | |||||||||||
|
Input Current |
S1 | mA | ≤220 | ≤60 | ≤55 | ≤35 | |||||||||
| S2 | ≤450 | ≤145 | ≤125 | ≤65 | |||||||||||
|
Input power |
S1 | W | ≤6 | ||||||||||||
| S2 | ≤12 | ||||||||||||||
| Speed | r/min | 1/1.2 | 1.5/1.8 | 2.5/3 | 4/4.8 | 5/6 | 8.3/10 | 10/12 | 16.7/20 | 25/30 | 30/36 | 60/72 | 80/96 | 80/96 | |
|
Output torque |
S1 | N.cm | 500 | 500 | 260 | 160 | 130 | 75 | 65 | 40 | 25 | 20 | 10 | 8 | 6.5 |
| S2 | 500 | 500 | 300 | 225 | 180 | 100 | 90 | 55 | 35 | 30 | 15 | 10 | 9 | ||
| Starting Voltage | V | ≤21 | ≤90 | ≤96 | ≤102 | ≤187 | ≤196 | ||||||||
| Temperature rise | K | ≤75 | |||||||||||||
| Application voltage | V | Rated voltage±10% | |||||||||||||
| Direction of operation | CW/CCW | ||||||||||||||
| Insulation degree | Class E | ||||||||||||||
| Capacitance | S1 | μF | ≤10 | ≤0.56 | ≤0.47 | ≤0.15 | |||||||||
| S2 | 15~35 | 0.68~2 | 0.56~1.5 | 0.22~0.47 | |||||||||||
2. Description:
Product Higholights
High Torque and efficiency with low noise
Speed state invariable not effected by voltage under rated frequency
Winding will not ruin when motor over loading or abrupt stop running
3. Mechanical Dimension:MM
4. Typical Applications
Electric screen
Electric oven
Ice machines
Food machine
Terrace monitor
5. Terms of trade
| Terms of price | FOB,CIF,CFR,EXW,DDP,etc. |
| Terms of payment | 100% T/T in advance for samples |
| Bulk quantity payment way can be negotited | |
| Warranty | 12 months limited warranty once the items are delivered to the buyer. |
| Lead time | Usually within 2 weeks for trial orders, within 3 weeks for bulk orders. |
| Package | Cartons /Pallets |
| Place of loading | Shanghai, Ningbo, etc. |
| Shipment carrier | Items are usually shipped via Fedex,DHL, TNT,UPS,EMS for trial orders and via vessel for bulk orders. |
| Delivery time | Usually within 5 working days by Express 15-30 working days by vessel |
